KZL-224 Automatic Stator Coil Winding Machine With Double Heads 4 Positions
Product Details:
- General Use Industrial
- Weight (kg) 2140 Kilograms (kg)
- Automatic Yes
- Control System Human-Machine Interface
- Power Source Electric
- Power Consumption 13.6 Kilo Watt (W)
- Drive Type Electric
- Click to View more
X
KZL-224 Automatic Stator Coil Winding Machine With Double Heads 4 Positions Price And Quantity
- 1 Unit
KZL-224 Automatic Stator Coil Winding Machine With Double Heads 4 Positions Product Specifications
- Electric
- 2330 x 1400 x 2500 Millimeter (mm)
- Electric
- Industrial
- Yes
- Human-Machine Interface
- 2140 Kilograms (kg)
- 13.6 Kilo Watt (W)
KZL-224 Automatic Stator Coil Winding Machine With Double Heads 4 Positions Trade Information
- Cash in Advance (CID)
- 10 Unit Per Month
- 30 Days
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Product Description
The KZL-224 Automatic Stator Coil Winding Machine is a state-of-the-art industrial solution engineered for precision, efficiency, and scalability. Featuring twin winding heads and four work positions, this machine maximizes productivity for varied manufacturing demands. With dimensions of 2330 x 1400 x 2500 mm and a robust weight of 2140 kg, it ensures stability and durable performance. Operated by an advanced Human-Machine Interface (HMI), it delivers intuitive control while consuming 13.6 KW of electric power. Designed to support a wide range of wire diameters (0.151.2 mm) and adaptable to copper, aluminum, and copper-clad aluminum wires, it ensures versatility for diverse stator coil winding applications. The machine is capable of handling stator overlapping thicknesses ranging from 20160 mm and works seamlessly with multiple motor pole configurations (2, 4, 6, 8 poles). Its fly fork diameter of 305 mm further enhances its operational precision. With air pressure requirements of 0.50.7 MPa for efficient operation, the KZL-224 is the ultimate automated solution for businesses looking to optimize industrial coil winding processes.
| Specifications | Parameter |
| Model No. | KL - 224 |
| Work Stations (Winding Heads): | 2 heads - 4 stations |
| Fly Fork Diameter: | 305 mm |
| Adaptive Wire Diameter: | 0.15 1.2 mm |
| Insulation Wire Materials | Copper wire, Aluminum wire, Copper clad aluminum wire |
| Applicable Motor Poles: | 2/4/6/8 |
| Suitable Stator Overlapping Thickness: | 20-160 |
| Air Pressure: | 0.5-0.7 Mpa |
| Power: | 13.6 KW |
| Net Weight: | 2140 KG |
| Diamension: | 2330 x 1400 x 2500 mm |
FAQs of KZL-224 Automatic Stator Coil Winding Machine With Double Heads 4 Positions:
Q: What type of wire materials can the KZL-224 machine handle?
A: It supports copper wire, aluminum wire, and copper-clad aluminum wire.Q: How many workstations does the machine have?
A: The KZL-224 features 2 winding heads and 4 workstations for efficient operations.Q: What motor poles are compatible with this machine?
A: It is suitable for motors with 2, 4, 6, and 8 poles.Q: What is the adaptive wire diameter range of the machine?
A: The machine adapts to wire diameters between 0.151.2 mm.Q: What is the required air pressure for operation?
A: The KZL-224 operates effectively at an air pressure of 0.50.7 MPa.Tell us about your requirement
